The Tube Rolling(Crimping) Machine is a high-efficiency, precision metal processing equipment specifically designed for continuously coiling metal strips into spiral rings or spring structures. Utilizing advanced automated control technology, it efficiently performs coiling, sizing, and cutting processes, making it ideal for producing various precision components such as spiral washers, elastic elements, and sealing rings. It is widely used in industries including automotive, machinery, electronics, and hardware.
Product Overview
The Tube Rolling(Crimping) Machine is a high-efficiency, precision metal processing equipment specifically designed for continuously coiling metal strips into spiral rings or spring structures. Utilizing advanced automated control technology, it efficiently performs coiling, sizing, and cutting processes, making it ideal for producing various precision components such as spiral washers, elastic elements, and sealing rings. It is widely used in industries including automotive, machinery, electronics, and hardware.
Key Features
High-Precision Forming
Servo motor-driven with high-rigidity molds ensures coiling dimensional accuracy within ±0.05mm and roundness error below 0.1mm.
Equipped with an automatic deviation correction system to prevent material misalignment and ensure consistent forming.
Efficient Automated Production
Integrated PLC + touchscreen control system supports parameterized settings, enabling quick switching between different product specifications with a single click.
Continuous operation of automatic feeding, coiling, and cutting achieves a production speed of 30-60 pieces per minute (depending on material thickness).
Wide Material Adaptability
Capable of processing stainless steel, carbon steel, copper, aluminum, and other metal strips, with a thickness range of 0.1-3mm and width range of 10-100mm.
Optional heating module for temperature-controlled coiling (suitable for hard alloys or special heat treatment requirements).
Modular Design
Quick mold and guide mechanism replacement allows product specification changes within 5 minutes.
Product Description
Tube rolling(crimping) machine is a professional automated device designed for the cylindrical forming of metal spiral mesh. Featuring a precision mechanical structure and an intelligent control system, it efficiently completes the rolling process of spiral mesh. It is particularly suitable for the filter manufacturing industry, producing both the inner and outer cylindrical mesh for filter cartridges. The machine processes flat sheet material through uncoiling, perforation, and rolling, automatically forming the required mesh cylinder with adjustable diameter and length, then cutting it into individual cylindrical sections. As the core support frame or filtration layer of the filter element, it ensures structural stability, uniform porosity, and meets high-precision filtration requirements.
Key Advantages
Specifications
1. Steel thickness: 0.4-0.8mm
2. Band width: 68mm
3. Working diameter: 45mm-135mm adjusted by molds
4. Total motor power: 4KW
5. Speed: 2.4m/min with a diameter of 87mm
6. Rotary cutting
7. External snap-in
8. Application: anti-fingerprint steel, hot-dip galvanize steel
9. Dimensions: 1700*1100*1500mm (length*width*height)
10. Punching diameter 6mm
11. Unwinding, punching and rolling included
Working Principle
1. Automatic Feeding – The spiral mesh is fed into the forming zone via a conveyor.
2. Perforation Section – Precise punching according to preset hole spacing.
3. Pre-Bending & Positioning – Guide wheels perform initial bending and shaping.
4. Cylindrical Forming – Main forming rollers complete the final rolling process.
5. Finished Product Output – Automatic unloading system collects the finished mesh cylinders.
Applications
