Technical parameters1. Working voltage: AC380V/50HZ2. Power: 5KW3. Diameter of coiling: 130 - 350MM4. Speed: 2 - 3 per minute5. Working air pressure: 0.6MPA6. Width of the sheet: 400MMModelMachine WeightEffective Working WidthFJDWJY-1050850KG1050MMFJ...
1. Working voltage: AC380V/50HZ
2. Power: 5KW
3. Diameter of coiling: 130 - 350MM
4. Speed: 2 - 3 per minute
5. Working air pressure: 0.6MPA
6. Width of the sheet: 400MM
| Model | Machine Weight | Effective Working Width |
|---|---|---|
| FJDWJY-1050 | 850KG | 1050MM |
| FJDWJY-1250 | 1100KG | 1250MM |
7. Machine weight: 600KG
8.Overall Dimensions: 1100MM * 1800MM * 1200MM
| Model | Overall Dimensions (LWH) | Overall Dimensions after Wooden Case Packing (LWH) |
|---|---|---|
| FJDWJY-1050 | 1650MM * 1700MM * 1200MM | 1810MM * 1860MM * 1450MM |
| FJDWJY-1250 | 1850MM * 1700MM * 1200MM | 2010MM * 1860MM * 1450MM |
